CTC–1210 Tertiary Impact Crusher 80-135 T/H

The CTC-1210 tertiary impact crusher stands as a specialized solution for operations requiring fine crushing and sand production capabilities. This stone crusher machine handles medium-hard, non-abrasive materials with exceptional efficiency, delivering cubical products down to 0.5 mm particle size with 60% passing rate in a single processing stage. Its design addresses the specific demands of aggregate production where particle shape and gradation matter significantly.

What sets this sand making machine apart is its ability to control upper product sizes while maintaining high reduction ratios. The rotor, measuring 1,100 x 1,000 mm, operates at speeds between 800 and 900 rpm, creating the impact force necessary for effective material breakdown. This configuration allows the crusher to process feed materials up to 120 mm while producing 80 to 135 tons per hour, powered by a robust 160 kW motor. The machine weighs 12,500 kg, reflecting its solid construction built to withstand continuous industrial operation.

Selective crushing represents a key operational advantage of this model. By adjusting rotor speed and breaker plate positioning, operators can fine-tune output characteristics to meet specific project requirements. This flexibility proves valuable when working with varying material types or when different product specifications are needed. The interchangeable wear parts extend equipment longevity and reduce downtime, as maintenance teams can quickly replace components without complex procedures.

The hydraulic opening mechanism significantly simplifies maintenance and adjustment operations. Instead of manual, time-consuming processes, operators use hydraulic controls to access internal components and modify settings. This feature translates to reduced maintenance windows and improved operational efficiency. When combined with the high crush count that produces superior cubical shapes, the stone crusher machine becomes particularly valuable for applications where final product quality directly impacts project success.

Closed circuit operation on smaller product fractions represents another practical capability. The crusher works effectively within crushing circuits where precise size control matters, making it suitable for sand production and fine aggregate manufacturing. The high reduction ratio means fewer crushing stages may be required, potentially simplifying plant layouts and reducing capital costs.

CONSTMACH has engineered this tertiary impact crusher to address real production challenges. Material enters the crushing chamber where the high-speed rotor propels it against breaker plates, creating the impact forces that fragment particles. The geometry and rotational characteristics ensure repeated impacts, generating the cubical shapes desired in quality aggregates. This differs from compression-based crushing methods that can produce more flaky or elongated particles.

The 80 to 135 tons per hour capacity suits medium-scale operations, whether in stationary plants or integrated crushing systems. Feed size acceptance up to 120 mm allows the machine to handle secondary crusher discharge effectively, positioning it well within typical multi-stage crushing arrangements. The specifications indicate thoughtful engineering focused on practical application rather than theoretical maximums.

For producers prioritizing sand quality and fine aggregate production, this equipment offers tangible benefits. The combination of controlled particle size distribution, cubical product shape, and operational flexibility addresses market demands for high-quality construction materials. Industries requiring specific gradations for concrete production, asphalt manufacturing, or specialized applications find value in the consistent output this stone crusher machine delivers.
