HP 100 Cone Crusher

When it comes to reliable crushing solutions for hard and abrasive materials, the HP 100 cone crusher stands as a proven performer in the industry. At CONSTMACH, we integrate this globally recognized stone crusher into our stationary and mobile crushing plants, utilizing premium METSO or SANDVIK brand equipment that sets industry standards. This strategic choice ensures our clients benefit from worldwide accessibility to operational support, maintenance services, and spare parts availability across any market.

The HP 100 operates on a compression-based crushing principle that delivers consistent results. The design features a movable cone mounted on a central shaft, positioned within a fixed outer shell. As material enters from the top feed opening, it travels into the crushing chamber where the eccentric movement of the cone compresses it against the stationary shell. This continuous squeezing action breaks down even the toughest rocks into progressively smaller fragments. The crushed material then exits through the bottom discharge opening once it reaches the desired size specification.

What makes this stone crusher particularly effective is its stepwise crushing process. Rather than attempting to break material in a single pass, the HP 100 subjects rocks to multiple compression cycles as they move downward through the chamber. This approach produces more uniform particle shapes and reduces internal stress on wear components, extending their operational life significantly. The adjustable crushing cavity allows operators to fine-tune output sizes with precision, making it adaptable to various production requirements.

CONSTMACH equips each HP 100 unit with a robust steel construction chassis, engineered platforms, and properly sized electric motors. The complete assembly weighs approximately 5,400 kg, with the bowl, bowl liner, adjustment cap, and hopper contributing an additional 1,320 kg to the total weight. The head mantle and feed plate assembly adds another 600 kg. We recommend a maximum power supply of 90 kW (125 HP) for optimal performance, with countershaft speeds ranging from 750 to 1200 rpm depending on application needs.

This stone crusher excels in processing granite, basalt, iron ore, and quartz - materials known for their hardness and abrasive characteristics. The compression crushing method proves particularly effective for these rock types, delivering superior throughput compared to impact-style crushers. Aggregate producers rely on the HP 100 for consistent gradation control, while concrete and asphalt plants value its ability to produce specification-grade materials efficiently.

The durability factor cannot be overstated. Wear-resistant components handle abrasive feed materials without rapid degradation, and the robust structural design withstands the constant forces generated during operation. Maintenance procedures remain straightforward, keeping downtime minimal and operating costs manageable. Energy consumption stays relatively low for the tonnage processed, contributing to better project economics.

CONSTMACH cone crushers combine proven engineering principles with quality manufacturing to deliver dependable crushing solutions. The HP 100 model represents an efficient, economical choice for operations requiring reliable secondary or tertiary crushing capacity. By partnering with CONSTMACH, you gain access to equipment built for performance and backed by responsive technical support, ensuring your crushing operations maintain productivity targets consistently.
